4 Bolt Trailer Hub Kit for 1-1/16" Spindle, 1350 lbs Capacity, CE Smith 13109

CE Smith 4 Bolt Trailer Hub Kit for 1-1/16" Spindle, part 13109

Shipshape Trailer Parts provides these convenient hub replacement kits for many trailer applications.

Features:

• Kit lets you replace 1 hub assembly on your trailer
  • Includes bearings, races, grease seal, grease cap, lug nuts, and cotter pin
  • Perfect for storing onboard your trailer in case of an emergency
• Pre-greased with heavy-duty, marine-grade lubricant
  • Ideal for boat trailers
• Strong, cast iron hub is painted black
• Double-lip grease seal helps keep moisture out and grease in
• Zinc plating on lug nuts, cotter pin, and grease cap helps to limit corrosion
• Carrying case with handle keeps all the parts in one place
• Made in the USA

Included:

• Hub
• Bearings
• Seals
• Dust cap
• Grease
• Lug nuts

Specs:

• Application: 2,700-lb axles
  • Maximum wheel diameter: 12"
• Painted cast iron studded hub for 1-1/16" spindle
• Bolt pattern: 4 x 4"
• Flange outside diameter 5-9/16"
• Weight capacity: 1,350 lbs
• Hub inside diameter 1.98"
• Maximum recommended wheel size: 12"
• Inner Bearing size: 1-1/16 inch, part # LM44649
• Outer Bearing size: 1-1/16 inch, part # LM44649
• Hub length: 4-1/8 inch
• Distance between races: 2-7/16 inch

Bearing, Race, and Seal Information:

• Bearings (included)
  • Inner and outer bearing: LM44649(1-1/16" inner diameter)
• Races (included)
  • Inner and outer race: LM44649
• Grease seal (included): 12192TB

Wheel Hub Parts Guide:

C. E. Smith Company, Inc. manufactures and sells replacement parts for small to mid-size boat trailers including trailer fenders, boat guides, galvanized bracketry, tire carriers, replacement wheel bearings, rubber rollers, roller shafts, u-bolts and other requirements for boat trailers.
